G0545 32W Active PoE Injector
PoE Injectors
G0545
A 32W IEEE 802.3af/at PoE+ injector for RUCKUS and Grandstream access points, PTZ cameras, video intercoms and higher-power IoT devices.
A 32W IEEE 802.3af/at PoE+ injector for RUCKUS and Grandstream access points, PTZ cameras, video intercoms and higher-power IoT devices.
Key Specifications
Injector TypeActive
Power32W
Output53V / 0.6A
PoE StandardIEEE 802.3af / 802.3at
Data Rate10G / 5G / 2.5G / 1G
Pair Type2-Pair
Input Range48–57V
Applications
Enterprise WiFi
IP Cameras & Surveillance
VoIP & IoT
Certifications & Compliance
- UL
- cUL
- CE
- FCC
- KC
- RCM
- PSE
- EAC
- BR
- BS
- PSB
- NOM
- Argentina
- BIS
- Mexico
Technical Specifications
General
| Injector Type | Active |
|---|---|
| Power | 32W |
| PoE Standard | IEEE 802.3af / 802.3at |
| Data Rate | 10G / 5G / 2.5G / 1G |
| Pair Type | 2-Pair |
Input / Output
| Input Range | 48–57V |
|---|---|
| Output | 53V / 0.6A |
| Pin Assignment | Mode B · 4/5 (+), 7/8 (−) · Customizable |
| Chipset | Microsemi |
