G1251-0150W CRPS Power Supply
G1251 150W CRPS Power Supply
Features
- Hot-plug
- Active Load Sharing
- Surge Immunity
- Reverse Airflow Option
- Smart Fan Control
- PMBus Monitoring
- OVP/OCP/SCP/OTP
- Hold-up Time
- Active PFC
Applications
Certifications & Compliance
- UL
- CE
- CB
- TUV
- CCC
- BSMI
- GMA
- FCC
- UKCA
Certifications vary by model. Please contact us for detailed certification information.
Technical Specifications
General Specifications
| Model | G1251-0150W |
|---|---|
| Rated Power | 150W |
| 80 PLUS Rating | 80 PLUS Gold |
| Typical Efficiency | 81% / 85% / 81% |
| Form Factor | 185mm CRPS |
Input Specifications
| Input Type | AC + HVDC Input |
|---|---|
| Input Voltage | 100-240Vac |
| HVDC Input | Supported, 240Vdc |
Output & Control
| Main Output | 12V / 12.5A |
|---|---|
| Standby Output | 12Vsb / 2.1A |
| PMBus | PMBus 1.2 |
| EDPP Support | Not Supported |
| Hold-up Time | 100% load: 10ms |
Mechanical & Environment
| Dimensions | 185 x 73.5 x 40 mm |
|---|---|
| Reverse Airflow Support | Supported |
| Connector | Card edge connector |
| Surge Immunity | 2KV 2ohm/1KV 2ohm |
| Operating Temperature | -5~55℃ |
Compatibility & Ordering Notes
Not all available models or project configurations are listed online. Please share your original PSU details or system requirements, and we can help confirm a suitable option.
Need a model not listed online?
Some models, configurations and project-specific versions may not be listed on the website. Please contact us with the required power rating, input range, output voltage, form factor and application details.
For replacement or upgrade projects
Please provide the original PSU model, system model, rated power, input/output specifications, airflow direction and connector details. Photos of the original PSU label, connector and installation position are highly helpful.
For new system integration projects
Share your system platform, power budget, redundancy plan, airflow design, PDB/backplane requirements and expected quantity. We can help recommend suitable CRPS, PoE PSU, PDB or related power solutions.
Project-based customization may be available
Airflow direction, connector options, cable/PDB matching, labeling or configuration adjustments may be supported depending on technical feasibility, MOQ and validation requirements.
Flexible MOQ and lead time confirmation
Flexible MOQ can be discussed for sample evaluation, replacement needs and project-based orders. Lead time depends on model, configuration and order quantity, with responsive delivery support for qualified project requirements.
